Material receipt
Mill certificates checked against order. Grade, thickness and finish verified and logged before stock is released.
Quality assurance
Inspected at six stages, not just at the end.
Finding a defect at final inspection means rework, delay and a difficult conversation. Finding it at fit-up means a five-minute adjustment. So we inspect early, and we write it down.
01 — Control points
The six-stage inspection process.
Each stage has a defined check and a sign-off. Work does not progress to the next stage until the current one passes.
Cutting & forming
First-off part dimensionally checked against the approved drawing before the batch runs.
Fit-up
Joint preparation, gap, alignment and squareness inspected before any welding is permitted.
Welding
Welds executed to qualified procedure by coded welders, then visually inspected 100%. DP and UT available on request.
Finish
Surface preparation, coating thickness and polish grade checked against specification.
Final & despatch
Full dimensional check against the signed drawing, photographic record, then protected for transport.
02 — Performance
Measured, not claimed.
These are our own rolling twelve-month internal records, reviewed quarterly. We publish them because a fabricator who will not measure their own delivery record usually has a reason.
“First-time inspection pass” means the item was accepted by the client or consultant without rework on first presentation.
03 — Documentation
What comes in the handover file
- WPS & PQR — welding procedure specifications and qualification records for the procedures used on your job.
- Welder certificates — current qualification records for every welder who worked on the package.
- Mill certificates — EN 10204 material certificates traceable to the heat number.
- Dimensional report — final check against the signed shop drawing.
- Photographic record — fabrication and installation stages documented.
- Method statement & RAMS — for any works carried out on your site.
- Warranty certificate — twelve months on workmanship as standard.
Tell us at enquiry stage if you need certified material — it changes procurement, so it cannot be added retrospectively.
04 — Machines & equipment
What is on our shop floor.
Profiling, forming, welding and finishing all in-house. That is what lets us control tolerance and lead time instead of explaining a subcontractor's delay.
PhotoCNC Press Brake — 3200 mm × 135 T
machine-cnc-press-brake.jpgCNC Press Brake
PhotoFibre Laser Cutter — 3000 × 1500 mm bed
machine-fibre-laser-cutter.jpgFibre Laser Cutter
PhotoCNC Plasma Table — 6000 × 2000 mm bed
machine-cnc-plasma-table.jpgCNC Plasma Table
PhotoHydraulic Guillotine — 3000 mm × 10 mm
machine-hydraulic-guillotine.jpgHydraulic Guillotine
- CNC Press Brake
- 3200 mm × 135 T
Programmable multi-axis bending with repeatable angle control. - Fibre Laser Cutter
- 3000 × 1500 mm bed
Burr-free profiling of steel, stainless and aluminium from DXF. - CNC Plasma Table
- 6000 × 2000 mm bed
High-speed profile cutting of plate up to 25 mm. - Hydraulic Guillotine
- 3000 mm × 10 mm
Straight, accurate shearing of sheet and light plate. - Plate & Section Rolls
- Up to 12 mm plate
Rolling of plate, pipe and section to specified radius. - Welding Bays
- TIG · MIG · MMA · FCAW
Multiple stations with fume extraction and positioners. - Ironworker & Punch
- Punch, notch, shear
Fast processing of angle, flat bar and light section. - Bandsaw & Cold Saw
- Up to 400 mm section
Square, mitre and repeat-length cutting of section and pipe. - Polishing & Finishing
- Mirror · hairline · No.4
Belt, mop and satin finishing for stainless architectural work. - Shot Blast & Paint Bay
- Sa 2½ preparation
Surface preparation and protective coating application.
05 — Certifications & standardsDocumented, licensed
Documented, licensed
and auditable.
Current copies of all licences and qualification records are available on request for tender and prequalification submissions.
Trade Licence
Licensed steel fabrication and metal works contractor in the Emirate of Abu Dhabi.
Welder Qualification
Coded welders with current qualification records available on request.
Quality Management
Documented inspection and traceability procedures across every project stage.
HSE Management
Method statements, risk assessments and toolbox talks on every site.
Material Traceability
EN 10204 certificates retained and issued with the project handover file.
Municipality Approved
Experience preparing and submitting fabrication packages for authority approval.
06 — Health & safety
Nobody gets hurt building your project.
Every site mobilisation is preceded by a method statement and risk assessment, reviewed with the crew before work starts. Hot works, work at height and lifting operations are permit-controlled.
- Task-specific method statements and risk assessments (RAMS)
- Trained and certified riggers, banksmen and scaffolders
- Hot works, confined space and work-at-height permits
- Daily toolbox talks and full PPE discipline
- Incident reporting and investigation procedure
- Third-party inspected lifting gear with current certificates
Materials we work in
- Mild steel
- S275 / S355 — sections, plate to 40 mm, hollow section
- Stainless
- 304 / 304L, 316 / 316L, 430 decorative
- Aluminium
- 6061 / 6063 extrusion, 5000-series sheet, ACP
- Protection
- Hot-dip galvanising, powder coat, duplex, epoxy
- SS finishes
- Mirror, hairline, satin, No.4, bead blast
- Welding
- TIG, MIG/MAG, MMA, FCAW — AWS & ASME procedures
Prequalification
Need our documents for a tender?
Trade licence, welder qualifications, insurance certificates and past-project references — send us the prequalification form and we will complete it.
